Compression spring machine is an indispensable machine and equipment for the forming, processing, and manufacturing of elastic yellow hardware accessories. The compression spring machine manufacturing industry also has great development prospects. Let's take a look at the structural performance of the computer compression spring machine.

Compression spring machine control system

Compression spring machines are operated by electric appliances, and the development trend of pedal type is to the spring machinery of CNC machine tools with integrated electromechanical engineering. The compression spring machine server is also changed from thick, black, and heavy cast iron parts to a carbon steel machine control panel, which improves the mechanical compressive strength and rigidity. The automatic closed worm gear and worm drive and lubricates the compression spring machine accuracy. Higher, higher efficiency and higher. The control system of the spring compression machine is composed of system bus, CPU, switching power supply, memory, control panel and display, position control module, programmable logic control module of programmable controller and its statistical data input/output socket.



The mechanical structure of the computer compression spring machine needs to be completely reformed
Each movement mechanism of the computer compression spring machine is independent, and each is controlled by a servo motor. If the wire feeding mechanism is just a simple gear drive, the wire feeding length can be unlimited; the upper and lower circle diameter rods and pitch rods are directly driven by the motor connected to the ball screw; the cutting mechanism is only a simple cam drive, except for general In addition to the cutting, it can also be matched with the upper and lower cutters for twist cutting to solve the spring cutting of large wire diameter and small winding ratio. When the operator needs to process different kinds of springs, for the computer compression spring machine, he only needs to fill in the corresponding parameters on the computer and coordinate the actions of the various mechanisms through the program control to circle the required springs.
