Product Details

10.4-inch color liquid crystal display industry;
Chinese / English interface, the state system for different customers;
U disk support function, easy software upgrades;
It supports USB and RS232 communication function, convenience and computer on-line;
Using ARM9 processor, higher processing efficiency;
It supports 4-axis servo control;
It supports 8 groups of probe cylinders;
An optional hand-held box, easy to adjust the machine;
Programming intuitive and easy to learn;
Complete information presentation system.

4-axis servo motor control, can be individually synchronized motion or movement, flexible and convenient way of programming;
8 set of probes and cylinder select, high-speed probe testing to ensure accurate processing of the spring;
With feed bobbin winding line break alarm detection and wire frame accelerated output delivery, flexible control feeding bobbin;
Handwheel debugging process and test process (or inching debugging process) and other functions, debugging more convenient;
Flexible jump function, with check-growth device for automatic separation of waste spring;
The outer diameter can be automatically corrected, pitch correction, sending length correction;
You can not stop running to change the processing procedures, improve work efficiency;
Complete and intuitive system status prompt, the user can find the problem, easy troubleshooting;
Have multiple sets of system parameters setting function, it can be very convenient for system parameters and system maintenance parameters change, and people with a password authentication to prevent unauthorized changes;
Storage capacity, up to 1000 processing file storage space;
Programming intuitive and easy to learn;
The system easy to upgrade, you can download the latest program updates through U disk.
